Step 3
3b. Befestigung an der Massivbetonwand
Loosen the shown screws in the middle of front panel and align the front plate making sure that it is parallel to the wall plate. After the
alignment tighten all 4 screws at medium strength.
X
±
Step 4
R Q P
Back view of right rail
All manuals and user guides at all-guidesbox.com
6
X=Y
°
P Q S
T
To insert the screw „P" easier, use the plastic forceps „T".
S Q
6
Front plate
P P Q R
Back view of left rail
T
