 Perform cleaning (see section 4).
3.6

ROCAM positioning

The positioning probe is built in the camera head spring. The positioning probe emits magnetic
fields that are received by the positioning receiver and are transformed visually and audibly.
The 512 Hz measuring system can penetrate masonry, stone, wood and plastic.
The intensity of the signal changes depending on the position and distance from the receiver.
3.7

Monitor unit with touchscreen

The ROCAM mini HD AMPShare comes with a SD card to save photo's and video's. This can be
removed for data transfer.
Connections HDMI, mini USB and SD card are on the bottom monitor unit
3.8

User interface

Brightness Indicator (0 – 4)
Zoom Level Indicator (1.0 – 3.0)
Adjustments
Foto/ Video Gallery
Battery Indicator:
Colour white:
to
tion
Colour red:
Battery empty,
to 50°C)
If the ROCAM mini HD AMPShare is used outside the specified operating temperature
range, faults can occur on the screen! The ROCAM mini HD AMPShare may switch itself
off autonomously!
22
Time
Take picture
Start/Stop Video
Up to 100%, up to 20% battery capacity,
battery temperature exceeds the operating temperature (0°
ENGLISH
Storage Indicator
Battery Indicator
Change Video/picture
Settings
mains network opera-
