TWINLINE AIR

DESCRIPTION OF FUNCTIONS OF THE OPERATION ELEMENT
1 Blue LED warning light:
When there is not enough water the blue LED blinks every 8 seconds.
When there is enough water for operation of the air system the blue
LED blinks every half a second.
2 LED colored lighting:
LED colored lighting - On - press once. The cycle of colors is started.
Remain on one color - press once. The color shown is retained.
Further colors - press several times.
LED colored lighting - Off - press and hold for approximately 2 secs.
Do not look directly into the ray of light from the operational LED colored
lighting lamp from the front. This may cause damage to your eyes.
3 Air system:
Air system - On - press once (functions when there is a small amount of
water at the bottom). Operation is shown by a blue LED. (The automatic
cycle limit is set for 20 minutes.)
Air system - Off - press once.
The jets are automatically blow dried after showering. This process begins
approximately 20 minutes after the end of the shower and lasts for
approximately 3 minutes.
Power connection: 230 V 50 HZ
Standby: 8 W
17
All manuals and user guides at all-guides.com
LED risk category 1
when within 40 cm
DIN EN 62471, 2008
Power consumption LED colored: 7 W
Power consumption max: 50 W
2
1
3
