9
Measurement-specific settings: Temperature range A / M
Measurement
Level/Span L/S ?
Setup
File
10.0
Measurement-specific settings: Measurement settings
Measurement
Adjustment
Alarm / ISO
Measurement Date / Time
Level/Span
System Setup
Setup
System Info
File Fact Default
10.1
Temperature unit
Measurement
Temp Range -20/350
Temp Unit °C
Amb Temp 25.8
Ref Type Off
Ref Temp 30.0
Auto ?
Temperature range / Auto (A)
This setting is used to adjust the temperature range
of the IR image and the resulting distribution of the
colour spectrum of the infrared image. The colour
spectrum of the measured IR image is determined in
relation to the temperature range and colour scale.
Min. value
The colour distribution of the IR image is auto-
matically and dynamically adjusted in the bargraph
based on the measured min./max. values.
L/S ?
Temperature range / manual (M)
In manual settings mode, the temperature
range is no longer set automatically based
on the measured min./max. values but rather
determined on the basis of manual values. The
user must define the temperature range and
span. Refer to Section 21.
°C
°C
°C
°C (Celsius)
°F (Fahrenheit)
K (Kelvin)
Max. value
Bargraph
Measurement
Temp Range -20/350
Temp Unit °C
Amb Temp 25.8
Ref Type Off
Ref Temp 30.0
10.2

Ambient temperature

Measurement
Temp Range
Temp Unit
Amb Temp
Ref Type
Ref Temp
ThermoXplorer Pro
°C
°C
°C
-20/350
°C
25.8
Off
30.0
°C
°C
°C
31
