11� Manufacturer's Warranty
As purchaser, you are entitled to your
statutory rights against the vendor. If
these rights exist in your country, they
are neither curtailed nor restricted by
our Warranty Declaration. We guarantee
that your STEINEL Professional sensor
G B
product will remain in perfect condition
and proper working order for a period of
1 3
5 years. We guarantee that this product
Y E A R Y E A R
is free from material-, manufacturing- and
design flaws. In addition, we guarantee
MANUFACTURER'S MANUFACTURER'S
WARRANTY WARRANTY
that all electronic components and
cables function in the proper manner and
that all materials used and their surfaces
are without defects.
Making Claims
If you wish to make a claim, please send
your product complete and carriage paid
with the original receipt of purchase,
which must show the date of purchase
and product designation, either to your
retailer or contact us at STEINEL (UK)
Limited, 25 Manasty Road, Axis Park,
Orton Southgate, Peterborough, PE2
6UP, for a returns number. For this rea-
son, we recommend that you keep your
receipt of purchase in a safe place until
the warranty period expires. STEINEL
shall assume no liability for the costs or
risks involved in returning a product.
For information on making claims under
the terms of the warranty, please go to
www�steinel-professional�de/garantie
If you have a warranty claim or would
like to ask any question regarding your
product, you are welcome to call us
at any time on our Service Hotline
01733 366700.
5
Y E A R
MANUFACTURER'S
WARRANTY
- 16 -
12� Technical specifications
Dimensions Concealed installation:
(W × H × D in mm) Surface-mounted installation:
Current consumption True Presence Multisensor KNX:
Multisensor AIR KNX:
Power supply KNX bus voltage 21-30 V
Mounting height 2 - 12 m
Detection zone 360°
Reach Ø 9 m True Presence (mounted up to a height of 4 m)
Ø 15 m presence
Ø 15 m movement
(can be set to within one centimetre)
Sensor values True Presence (only True Presence Multisensor KNX)
Light measurement with 2 spectra
(daylight and artificial light)
Temperature: 0°C to +40°C
Air pressure 300-1200 hPa
Relative humidity: (0% - 100%)
VOC: 0 ppm - 1000 ppm
CO₂: 300-5000 ppm
True Presence Multisensor 4× light output (ON/OFF, dimming level, scene) dimming
KNX outputs level with effect light
Radial approach/leaving/standing
Radial distance
Constant-lighting control with 2 channels with effect light
HVAC, presence, CO₂, VOC, temperature,
relative humidity, dew point, logic gate
Time setting 10 seconds to 18:12:15 hours (hh:mm:ss), IQ mode
Multisensor AIR KNX outputs HVAC, VOC, temperature, relative humidity, dew point,
logic gate
Twilight setting 2 - 1000 lux
Temperature range 0°C to +40°C
IP rating IP20
True Presence frequency 7.2 GHz (responds to micro-movements resulting from
the vital functions)
UWB transmitter power -14 dBm
Bluetooth frequency 2.4-2.48 GHz
Bluetooth transmitter power 5 dBM/3 mW
123 × 123 × 33
142 × 142 × 44
40 mA
15 mA
