Product dimensions, concealed
installation (Fig� 3�3)
Product dimensions, surface-mounted
installation (Fig� 3�4)
Detection zone (Fig� 3�5)
4� Installation
Wiring diagram (Fig� 4�1)
5� Mounting
• Check all components for damage.
• Do not use the product if it is damaged.
• Select an appropriate mounting loca-
tion, taking the reach and presence
detection into consideration.
• Switch OFF power supply (Fig� 4�1)
Mounting procedure, concealed
installation
– Firmly screw the mounting frame onto
the mounting box (Fig 5�1)
– Make plug connection (Fig� 5�2)
– Position sensor on the mounting frame
(Fig� 5�3)
• The sensor is held on the frame by
magnetic force.
Mounting procedure, surface-mounted
installation
– Drill holes and screw on surface-
mounting adapter (Fig� 5�4)
– When mounting with exposed cable,
break out the mounting tab (Fig� 5�4)
– Firmly screw the mounting frame
onto the surface-mounting adapter
(Fig 5�5)
– Make plug connection (Fig� 5�6)
– Position sensor on the mounting frame
(Fig� 5�7)
• The sensor is held on the frame by
magnetic force.
Note:
When setting the reach, the mounting
height needs to be specified via the ETS
Note:
Surface-mounted installation has influ-
ences on the sensor variables measured.
For this reason, correction factors are
implemented in the software which take
effect by activating the "surface mount-
ing" type of installation in the ETS.
6� Function and settings
Factory settings
– No factory settings are made
First time of use
During initial commissioning, the presence
detector creates a room image. The room
must be free of movement for 2 to
2.5 minutes for this.
Note:
An image of the room is also created if
reach or mounting height is changed.
The ETS can adjust the sensitivity of the
True Presence Multisensor from 1 (= low)
to 9 (= high).
The functions to be used (activated) are
set in the "General Settings" parameter
window using the ETS.
Note: You will find an application
description at knx�steinel�de.
1. Issue physical address and generate
application program in the ETS.
2. Load the physical address and appli-
cation program into the multisensor.
When you are prompted, press the
programming button A (Fig� 4�1).
- 14 -
Smart Remote app
To read off and activating the program-
ming mode of the multisensor via smart-
phone or tablet, you must download the
STEINEL Smart Remote app from your
app store. You will need a Bluetooth-
capable smartphone or tablet (Android
version 5.0 or higher, iOS version 8.0 or
higher).
Android
iOS
LED function
Initialisation:
LED white
Normal mode:
LED OFF
Bluetooth connection active: LED blue
Error:
LED red
Programming mode:
LED green
7� Accessories
Surface-mounting adapter
(EAN: 4007841 063870)
8� Maintenance / care
The product requires no maintenance.
The multisensor can be cleaned with a
damp cloth (without detergents) if dirty.
9� Disposal
Electrical and electronic equipment,
accessories and packaging must be
recycled in an environmentally
compatible manner.
Do not dispose of electrical and
electronic equipment as
domestic waste.
EU countries only
Under the current European Directive on
Waste Electrical and Electronic Equip-
ment and its implementation in national
law, electrical and electronic equipment
no longer suitable for use must be
collected separately and recycled in an
environmentally compatible manner.
10� Conformity
STEINEL Vertrieb GmbH hereby declares
that the True Presence Multisensor KNX /
Multisensor AIR KNX radio equipment
type conforms to Directive 2014/53/EU.
The full wording of the EU Declaration of
Conformity is available for downloading
from the following Internet address:
www.steinel.de
