2. Installation in the car (fi g.2)
Fig.2
5
Place the on the car seat, set your child in and secure your child with the
capsula® JR
lap (O) and diagonal belts (N) of the three-point-vehicle-belt. Now fasten the three-point
seat-belt with an audible »click« sound (fi g.2). Make sure that the lap belt runs under the
fi xation lugs (C) on both sides and that the diagonal belt leads only under the fi xation lugs
(C) on the side of the belt buckle (Q).
Fig.2.1
Finish the fi xing of the belts by fi xing the belt block anchor (D), only if delivered with. This
piece makes sure the diagonal belt (N) lies fi rmly over the child's shoulder and optimizes the
belt guidance. Thread the belt block anchor (D), which is fi xed on the back side of the seat
part, onto the diagonal belt (N) at the height just behind the child's shoulder.
The string to fi x the belt block anchor to the seat must lead behind the back of the child.
Warning:
Do not fasten the belts in any other way than described here, otherwise the child will not be
held or secured properly. Make sure that the diagonal belt is carefully positioned and does
not run too close to the child's neck. All belts must lie fi rmly against the child's body without
twisting. If necessary, install a height adjuster mechanism into the car to
correspond to your child's size.
Attention:
This fi xing keeps the booster fi rmly in place in case of the non activated retracting system.
Always keep it with the seat as it avoids injury in case of accident!
9

3. Care Instructions

To wash the seat cover, simply peel it off in an upwards motion.
The cover can be washed at 85ºF/30ºC.
Attention: Please do not spin. Do not dry in a dryer.

4. Important Notices

5
• The child seat is approved in accordance to the European Standard
capsula® JR
for child restraint systems ECE R44/04. The test symbol as well as the permit number can
be found on the orange label at the bottom of the seat.
• This child seat can only be used in vehicles with three-point seat-belts, that are approved
by the ECE regulation No.16 or other comparable standards. It is strictly forbidden to
install this seat with the lap belt alone.
• It is not allowed to do any changes on the seat or the belts.
• Each change of any part of the seat, which is not done by the manufacturer, will cause
the expiration of the ECE- approval and excludes immediately any warranties.
• Should any doubts or problems occur, contact your supplier, dealer or
HEYNER MOBIL AUTOMOTIVE GMBH.
• After an accident, the entire child restraint system should be replaced or least sent to
the manufacturer for inspection, together with the accident report. The service cost will
be charged.
