capsula JR5 Bedienungsanleitung Seite 6

English
Index / page
1. Using the 5 as a child car seat
capsula® JR
2. Installation in the car
3. Care instructions
4. Important notices
5. Some fi nal hints
Operating Instructions
A Cover
B Seat base
C Fixation lugs for
three-point-vehicle belt
D Belt block anchor
7
S. 6
S. 7
S. 8
S. 8
S. 10
N Diagonal belt of the
three-point-vehicle belt
O Lap belt of the
three-point-vehicle belt
P Belt latch of the
three-point-vehicle belt
Q Belt buckle of the
three-point-vehicle belt
1. Using the 5 as a child car seat
capsula® JR
You have purchased the
capsula® JR
We thank you for your trust. Please note, that the optimum safety characteristics can
only be achieved, if the seat is used properly according to instructions. Therefore we ask
you to ensure the correct installation of the seat in your vehicle by reading the operating
instructions carefully. Please keep instructions always with the seat for further information.
Only to be assembled by adults!
Recommendation:
recommends to use the
capsula® capsula® JR
a weight of 22 kg and up (Group III).
1.1. Preparation (fi g.1)
5
The may be placed on all passenger seats of the vehicle that are equipped
capsula® JR
with a three-point-vehicle-belt. The child seat must not be positioned on a vehicle seat,
which only has a lap belt (O), example given the centre back seat of cars with three seats
in the back.
1.2. Three-point-vehicle-belt confi guration (fi g.3)
The tree-point-belt of a vehicle is made of 4 parts: the lap belt (O), the diagonal belt (N),
the belt latch (P) and the belt buckle (Q).
English
5
car seat for your child.
5
booster seat for children with
GB
8
