Schreder TFLEX BASE Installationsanleitung Seite 5

3
D
UNPLUGGABLE TYPE
01-51-820 | DOC-0018124 rev H | 04-2022
A
M8
+0.2 Nm
20 Nm
-0.2 Nm
A
B
C1
C2
kg/lb
C1
B
0°
ROAD
www.schreder.com
488.2 mm
19.2 in
415.2 mm
16.3 in
171 mm
6.73 in
75 mm
2.95 in
11 kg
24.25 lb
C2
5/12
