Schreder TFLEX BASE Installationsanleitung Seite 2

ANSI 3G SWIVELING FIXATION
ROOF
C1
B
0°
ROAD
01-51-820 | DOC-0018124 rev H | 04-2022
40° 90°
-10° +10°
10°
40°
319 mm
C4
12.5 in
115,8
A2
A1
C2
ROAD
www.schreder.com
ROAD
146,2
122,2
A1
A2
415,2 mm
B
C1
C2
C3
kg/lb
C3
ROAD
C4
R 4,5
R 4,5
516 mm
20.31 in
492 mm
19.37 in
16.3 in
150,5 mm
5.92 in
185 mm
7.28 in
182 mm
7.16 in
10,7 kg
23.59 lb
10°
2/12
