4. Close the rear discharge flap.
3.5 SET THE BLADE/CUTTING
HEIGHT
The machine can be set to different blade/cutting heights.
Figure 7
1. Pull the height adjustment lever rearward to increase the
blade/cutting height.
2. Push the height adjustment lever forward to decrease the
blade/cutting height.
3.6

INSTALL THE BATTERY PACK

Figure 8
WARNING
• If the battery pack or charger is damaged, replace the
battery pack or the charger.
• Stop the machine and wait until the engine stops before
you install or remove the battery pack.
• Read, know, and follow the instructions in the battery
and charger manual.
1. Open the battery compartment flap.
2. Align the lift ribs on the battery pack with the grooves in
the battery compartment.
3. Push the battery pack into the battery compartment until
the battery pack locks into place.
4. When you hear a click, the battery pack is installed.
5. Close the battery compartment flap.
NOTE
The engine starts only when you put in the safety key.
3.7

REMOVE THE BATTERY PACK

Figure 8
1. Open the battery compartment flap
2. Remove the safety key.
3. Push and hold the battery release button.
4. Remove the battery pack from the machine.
4

MOWER FUNCTIONS

In general, a lawn mower is featured with four functions
(rear bagging/ rear discharging/ mulching/ side
discharging). These functions can be converted by changing
accessory setting. Please see the following table for detail
setting.
Please be noted that functions below vary with the mower
models.
NOTE
English
TO CONVERT MOWER
For rear discharging
For rear bagging
For mulching
"√" : installed
"×" : removed
5

OPERATION

Wear eye protection during operation.
5.1

START THE MACHINE

Figure 9
1. Put in the safety key.
2. Push and hold the start button.
3. While you hold the start button, pull the handle switch in
the direction of the handle bar.
4. Release the start button to start the machine.
5.2

STOP THE MACHINE

Figure 9
1. Release the handle switch to stop the machine.
Wait until the blade fully stops before you start the machine
again. Do not quickly turn the machine off and on.
Always remove the safety key and battery pack after you
complete the work.
5.3

EMPTY THE GRASS CATCHER

1. Stop the machine.
2. Remove the safety key.
3. Remove the battery pack.
4. Open the rear discharge flap and hold it.
5. Hold the grass catcher by its handle and unhook it from
the slots.
6. Close the rear discharge flap.
7. Empty the grass catcher.
5
MULCH GRASS
PLUG BAG
× ×
× √
√ ×
WARNING
WARNING
WARNING
