GB
Installation must be performed in compliance
with applicable local construction and plumbing
regulations. If in doubt, contact GROHE or an
expert. The safety device within the fitting
protects the drinking water quality and must not
A
be modified and should only be replaced by an
expert.
The installation of the S connector can be
challenging. To avoid damage to the piping, we
recommend that an expert perform this task.
C
Thermostats must be installed with the
adjustment in temperature at 38°C to meet the
necessary safety-related requirements.
E
Check at regular intervals to make
sure that the installation is not leaking.
G
To avoid tile damages, we recommend drilling
into the joint. Tiles can additionally be protected
with suitable adhesive tape.
I
Before changing the fitting switch off main shut-
off valve.
B
CAUTION!
Do not overtighten the screw connections, even
with the seal inserted, to avoid damage.
D
Temperature end stop
If the termperature end stop is at 43°C, insert
accompanying temperature limiter in
temperature selection handle.
F
If temperature connections are reversed (hot on
right - cold on left) the thermostatic compact
catrridge needs to be replaced. A qualified
expert is recommended for this.
H
Before drilling, ensure no pipes or electric cable
running behind the wall at the corresponding
location.
J
