DESCRIPTION AND ASSEMBLY
A - Vacuum head.
B - Switch.
B1 - Switch only for
B2 - Bag full Pilot light
E - Filter cartridge
F - Hooks for tightening of vacuum head to tank.
G - Suction inlet.
H - Tank.
L - Flexible hose.
M - Tube.
N - Adaptor.
O - Wand.
P - Round brush.
Q - Flat lance.
R - Dust tool.
S - Paper/cloth bag (OPTIONAL)
INDICATIONS TO BE SCRUPULOUSLY ADHERED TO
• This apparatus is not to be used by people (children
included) with reduced physical, sensorial or mental
capacities or without any experience and knowledge,
unless they did not receive instructions relative to the
use of the apparatus and are controlled by a person
responsible for their safety.
• Children should be controlled so that they didn't play with
the apparatus.
• The packaging components could constitute potential
dangers (as for example plastic bags): they must be kept
away from children's reach and from other people or
animal not conscious of their actions.
• Any different use from that indicated in this manual could
constitute a danger, therefore, it must be avoided.
• ATTENTION: this apparatus can be used for suction dry
only, and it cannot be stored in the open or under damp
conditions.
• ATTENTION: Don't ever point the suction opening towards
delicate parts of the body – of people or animals - such as
eyes, ears, mouth, etc.
• ATTENTION: if the apparatus is fitted with a supplementary
plug, do not exceed the power reported on the plug. Non-
compliance with this norm could cause fires and damages
even lethal to the user.
• ATTENTION the apparatus is not suitable for areas
protected against electrostatic discharges.
• ATTENTION: use only the brushes supplied with the
apparatus or those specified in the instruction manual.
Using other brushes could jeopardize safety.
• ATTENTION: Do not leave the functioning apparatus
unattended, always remove the plug from the socket
when not using the apparatus and store it away from the
reach of children or people who are not conscious of their
own actions.
• ATTENTION: Do not exhaust toxic, explosive, flammable
or incandescent substances. The maximum temperature
allowed is (40°C / 104°F) (120°C / 478°F).
• Every part of the apparatus must be correctly assembled
12
OPERATING INSTRUCTION
-
Assembly the head on tank and lock it by hooks
(Fig. 1)
-
Connect the flexible hose into the inlet (Fig. 2).
-
Connect the wand and the extensions to other side
of flexible hose (Fig. 3).
-
Select the most suitable accessory (Fig. 4).
-
Connect the plug to power socket then switch on
the equipment (Fig. 5).
-
Example of use of flat lance (Fig. 6).
-
Example of use of round brush (Fig. 7).
-
Example of use of brush ob the floor (Fig. 8).
-
If a paper/cloth bag is provided, insert it in the
tank on the deflector (Fig. 9).
before using it. Verify, furthermore, that the filtering
elements have been correctly and efficiently assembled.
• Ascertain that the values indicated on the engine block
correspond to those of the network to which you intend to
connect the apparatus and that the socket is compatible
with the plug.
• Do not aspire materials that could damage the filtering
elements (such as glass, metal etc.).
• Do not ever pull or lift the apparatus through the electrical
cable.
• Do not immerge the apparatus into water and neither use
water jets to clean it.
• Always remove the plug from the socket before performing
any operation.
• Regularly control the feeding cable looking for damages,
cracks or ageing. Substitute the cable before using it
further.
• The substitution of the damaged cable must be done by
the tech assistance service or by competent authorized
personnel with recognized qualification.
• When using electrical extensions, make sure that these
are compatible with the power cable and that it does not
touch liquids or conductive surfaces.
• Specialized personnel must always carry out maintenance
and repairs; any damaged part must be substituted with
original spare parts.
• ATTENTION: it is forbidden to carry out changes to
the apparatus. Tampering could cause fires and damages
even lethal to the user and the forfeiture of the guarantee.
• The manufacturer declines any responsibility for
damages caused to people or things due to non-
compliance with these instructions or if the apparatus
is unreasonably used.
Performance: -dryCAT 133 IC-HC:
1200 W max - 22560 hPa - 200 m3/h
-dryCAT 262 ICT-HC:
2400 W max- 22560 hPa - 400 m3/h
