2 1. Safety information
4 2. Unpacking and preparation
6 3. Installation and start-up
6 3.1 Installing the fixture
6 3.2 Connecting to mains supply
7 3.3 Connecting the control signal line: DMX / Art-Net
7 3.4 Switching on the fixture and basic SetUp
9 4. Dimensions
M N XTYLOS
USER INFORMATION
INDEX
Congratulations on choosing a Claypaky product
We thank you for your custom.
Please note that this product, as all the others in the rich
Claypaky range, has been designed and made with total quality
to ensure excellent performance and best meet your
expectations and requirements.
The Mini Xtylos is a compact beam moving light with unique optical
and chromatic characteristics, making use of a tailor-made laser
source (Patent Application filed). This laser source, lasting for
10,000 hours, is enclosed in a reliable, safe and fully sealed
module and it is the powerful engine of an incredible array of colors.
The beam aperture is set with a Zoom range from 1° to 4°.
The Mini Xtylos uses laser technology with RGB additive color
mixing. In contrast to the subtractive mixing used with discharge
lamps, colored light beams are as bright as a white light beam
The range of effects features a wheel with 2
prisms and one frost filter on a dedicated channel.
The Mini Xtylos is definitely the most dynamic light on the
market. It is the first moving head light with a laser light source,
and this opens up new, surprising prospects for the development
of the entire entertainment lighting world.
CJ3003
