Product overview

1x
1
Oil tank lid
2
Motor housing
3
Sleeve
4
Upper pole
5
Front handle
6
Harness
7
Harness connector
8
Main handle
9
Release switch
10
On/Off switch
1x
11
Battery release button
12
Battery (not included)
13
Cutting device cover
14
Saw chain
15
Guide bar
16
Oil level indicator
17
Chain tensioning screw
18
Fixing screw
19
Sprocket cover
20
Sprocket cover wheel
1x
ATTACH MOTOR HOUSING
1
Insert the
bar 4
into the motor hous-
DE
ing
2, so that the locking pin snaps
Lieferumfang
into the little hole in the motor hous-
FR
ing.
Etendue de livraison
IT
Materiale compreso nella fornitura
NL
Leveringsomvang
SV
SET POLE LENGTH
Leveransomfång
1
(Release fixing
screw  18
counter-
CZ
clockwise. Set the
Rozsah dodávky
pole 4
to a suitable
length. Fasten the fixing screw clock-
SK
wise.
Rozsah dodávky
RO
Caution! Loose connections may
Volumul livrat
cause loss of control and injuries.
GB
Scope of delivery

Intended use

1x
This garden tool is
-
intended to take care of trees and bushes
in the private sector;
-
not intended to cut trees;
-
not suitable for sawing plastic, masonry or
building materials which are not made of
wood,
-
to use according to the descriptions and
safety instructions indicated in this operat-
ing manual.
Any other use is not as intended. Improper use
is not covered by the warranty and the manu-
facturer will reject any liability. The user is li-
able for all injuries to third parties and damage
to their property.
1x
2
Subsequently, screw the
sleeve  3
firmly against the motor housing.
FILL IN CHAIN OIL
2
Unscrew the oil tank lid 1.
Fill the oil tank up to max. and close
the oil tank lid (see section "Lubricat-
ing the chain".
Caution! Make sure the tool is
switched off and the battery removed.
EN
EN
209
209
