B
Ø32-Ø60mm Ø32-Ø76mm
Ø
C 1
2
Operating range 130°
+120°
01-14-952 | DOC-0017499 rev H | 08-2022
2xM10
POST
TOP
+30°
-10°
POST
SIDE
TOP
ENTRY
-10°
5
+1
22 Nm
-1
No lubricant or TIKAL Tef-Gel only
4 turns
maximum
SIDE
ENTRY
0°
+30°
-100°
www.schreder.com
2xM8
6
+30°
0°
-30°
2/6
