6. ASSEMBLY INSTRUCTIONS
STEP 3
1. Fasten the xed handlebar (40) to the handlebar tube (32). Fasten with two sets of hex
screws (4) and at washers (24).
2. Loosen the four screws (45) on the back of the computer (46).
3. Connect the upper computer cable (41) and the pulse sensor cable (48) to the connections
on the back of the computer (46).
4. Place the computer (46) on the computer support on the handlebar tube. Secure the
computer with the four screws (45) removed earlier.
46
45
41
32
48
40
24
49
4
1
