Tally Dascom 5130P
Component
Cover
Control panel
Power switch
Paper loader
Print head
Control lever
Ribbon cartridge
Ribbon guides
Serial interface
Parallel interface
USB interface
Power receptacle
Tractors with
paper feed lever
(option)
Function
Protects print head and other components inside, and reduces noise.
Shows printer status for printer function setup.
Powers printer ON or OFF.
Paper feed path for single ply and bankbook/passport
24-pin printing mechanism
Lifts up the top of mechanism to install ribbon cartridge.
Ribbon fabric is installed inside.
For guiding ribbon installation on print head.
Connects serial interface cable from the host.
Connects parallel interface cable from the host.
Connects USB interface cable from the host.
Connects power cord to the printer.
For feeding and adjustment of continuous forms.
5
