WB 110-260
Technical specifications
Saw Stand
Stand Width
Stand Width
Extended
Folded Stand
Height
Assembled Stand
Height
Stand
Weight(without
brackets)
Stand
Weight(with
brackets)
Allowed Load
Overview (see figure A and B)
The numbering of the product features refers
to the illustration of the stand on the graphics
page.
1
Work Support Locking Knob
2
Work Stop Locking Knob
3
Work Stop
4
Extension Rail
5
Saw Mounting Brackets
6
Work Support
7
Extension Rail Locking Knob
8
Carry Handle
9
Mounting Bracket Locking Levers
10 Storage Trays
11 Carriage Bolt (M8 x 60 mm)
12 Locking Pin
13 Leg Release Lever
14 Locking Nut
15 Adjustable Foot
16 Hexagon Socket Head Bolt (M8 x
45mm)
17 Flat Washer
18 Spring Washer
WB 110-260
m
1.18
m
2.64
m
0.25
m
0.93
Kg
15.7
Kg
17.2
Kg
400
Assembly
Unpacking and checking contents
(see figure B)
Please also observe the representation of
the delivery scope at the beginning of the
operating instructions.
Before assembling the saw stand, check if all
parts listed below are provided:
Item
Description
Miter Saw Stand
Frame
Saw Mounting
5
Bracket
6
Work Support
3
Work Stop
Work Stop Locking
2
Knob
Locking Knob(Work
1&7
Support &
Extension Rail)
Carriage Bolt(M8 x
11
60mm)
Hexagon Scket
16
Head Bolt(M8 x
45mm)
17
Flat Washer
18
Spring Washer
Tools Needed For Assembly
■ 6mm Hex Wrench (supplied)
■ Adjustable or 11mm Open End Wrench
(Not supplied)
■ Phillips
®
Screwdriver (not supplied)
Assembling the Saw Stand
Carefully remove all parts included in the
delivery from their packaging. Remove all
packaging material.
Setting Up the Saw Stand (see
figures C)
– Lay the saw stand upside down on the floor
(legs facing upward).
– Press the Leg Release Lever (13) to
disengage the locking pin (12). Rotate the
leg up until the locking pin clicks into place.
– Repeat this step with the other three legs.
– Turn around the saw stand to the working
position.
Qty
1
2
2
2
2
4
2
4
4
4
15
