DESCRIPTION OF THE PARTS
5. DESCRIPTION OF THE PARTS
H-LINK
Power Not
connection cable
cord used
6. TECHNICAL DATA
• Supply voltage: 230V/50Hz (30mA)
• Wattage: 7W (maximum)
• Dimensions (mm): 123 x 115 x 37
• Weight (g): 214g
• Class 2 reinforced insulation device
• Operating Temperature: 0°C to + 40°C
• Operating Humidity:
between 30% and 80%.
• Equipment protection rating: IP21
• Maximum altitude for use: < 2000m
7. COMMUNICATION
• Wifi: 2.4 GHz Wi Fi (IEEE 802.11
b/g/n) (2412 ~ 2484 MHz)
• Bluetooth: 5 (LE) (2402~2480 MHz)
• YUTAKI H-LINK:
✓ Communication line: Use
0.75mm cable, 2-Conductor,
2
Stranded Copper
✓ Communication system:
Half-duplex
PMML0635 rev.1 - 03/2023
✓ Communication method:
✓ Transmission Speed: 9,600
✓ Wiring length: 1,000m maximum
✓ Maximum number of
7.1 Simplified declaration of
Button 2
Button 1
Yellow LED
Hereby, Johnson Controls-Hitachi
for remote
declares that the radio equipment
update
type 2 is in compliance with EU directive
Green LED
2014/53/EU and UK S.I. 2017 No. 1206
for Cloud
relating to radio Equipment.
connection
8. OPERATION INSTRUCTIONS
ATW-IOT-01 product allows remote
management and monitoring of Hitachi
Heating units by means of a mobile
application.
ATW-IOT-01 product collects Hitachi
Heating unit data available on the H-Link
line and send it to the cloud by means
of a Wifi link.
Whenever it is required to do any kind of
configuration of the ATW-IOT-01 device
(such as WI-FI configuration...) it is
requested the device password.
This password is written on the plastic
box label. For security reasons, this
password can be modified by user.
8.1 Button functionality
Button 1 Button 2
15 sec
15 sec
Asynchronous
bauds
(total length of H-LINK I/O bus)
ATW-IOT-01 per H-LINK line: 1
conformity
-
password reset
Factory reset
15 sec of the IOT +
Cloud data
Action
Wifi and
