06.
Once you have set the pack's dMX address be sure your controller's address matches that of the pack's.
07.
Your pack will now operate as dMX dimmer, you may control the light output intensity through your dMX
controller. 0 will give no output and 100 will give you full output.

REPLACING FUSE

to replace the protective fuse, use a flat head screwdriver to unscrew the fuse holder. Pull out the fuse. insert a
new and exact same type fuse back into fuse holder and tighten. always replace with the exact same type fuse
or other type one approved by our authorized service technician.
CAUTION: Always disconnect the units main power before performing any type of
service or fuse replacement!

POWER SUPPLY

Before plugging your unit in please make sure the source voltage in your area matches the required voltage for
your device. Because line voltage may vary from venue to venue, you should be sure to plug your power supply
into a matching wall outlet before attempting to operate you device.

PRODUCT DESCRIPTION

the unit is 1, 2, or 4 channel dMX dimmer Pack. this pack can serve as a stand-alone chaser or a dMX dim-
mer pack. it is designed as zero-crossing circuitry to eliminate inductive loads, so it is 100% safe for use with all
lighting fixturess comes with transformers. each channel is assigned with onel output socket for total of four. this
unit features XlR female and male connectors for dMX compatible. each channel is equipped with a 6.3a fuse.
and a maximum output load of 6.3a per channel or 16a totally.
Technische Daten
iteM naMe..................................................................................lightmaxx Multi dimm MKii
POWeR..................................................................................................... aC 220V 50Hz
unit siZe..............................................................................................260 x 190 x 75mm
unit WeigHt.......................................................................................................2.7Kgs
Fuse............................................................................................F6.3a 250V 5x20mm, 4PCs
