OPERATION
the unit has two switchable working modes. it can be used as a four-channel chaser or as a 1, 2, or 4 channel
dMX dimmer pack. Please follow up the instructions below to operate the unit for your desired performance.
CHASE MODE
Choose this working mode only when you want the device to act as a 4-channel chaser. this device has 16 built-
in programs. You can select to run any of these programs specifically, or set the unit to chase in a random se-
quence among all 16 built-in programs for a more dramatic show effect. the chase speed can also be adjusted.
01.
Connect your lighting fixture to any of the four power sockets on the pack.
02.
use the mode button to select chase mode: Chase mode is indicated in lCd display as "Pa" followed by
numbers 01-16. "Pa" stands for Program applied. if an "a" appears in the lCd display, you are in dMX
mode, "a" stands for address.
03.
set you desired chase pattern: Once you have selected the chase function, use the Menu button to select
your desired chase. the chase pattern is represented in the lCd display by "P" followed by two numbers.
You may select any of the 16 built-in programs to run at a single time.
04.
set you desired chase speed: at this point you may change the program chase speed. While in chase
mode, tap on the Menu button until the "sP" followed by two numbers is displayed in the lCd. then
use the ▲and ▲ buttons to adjust the chase speed. a value of 99 will give you the fastest chase speed
(about one step per 0.1 second). a value of 01 will give you the slowest chase speed
(one step per 30 second).
05.
You may now change the light intensity: use the Menu button to select "d" on the lCd.
use the ▲ and ▲ buttons to change the light output intensity. 00 will give the lowest output and 99 will
give you full intensity.

DMX MODE

use this operating mode only if you plan to use your pack as a dMX dimmer. this function will allow you to turn
on and control the intensity of non-dMX with the use of a dMX controller. On, Off, and dimming functions can
be performed through this pack. You may also set your dimmer pack to function as a 1, 2, or 4 channel dMX
dimmer pack, which means you can combine the output functions.

DMX Operation

01.
Connect a dMX controller to your dimmer pack via the 3-pin XlR connector.
02.
Connect your lighting fixture to any of the four power sockets on the front of the pack.
03.
decide if you are going to use your dimmer pack as 1, 2, or 4 channels. this function allows you to:
Control the output to all four outlets with one dMX channel.
group outlet channels one and two and group outlets channels three and four. the first group will be
controlled by one dMX channel and the second group will be controlled by another dMX channel.
this gives the pack a dMX value of two. the default setting is a four channel dMX switcher, each channel
is controlled by one dMX channel.
04.
to change the channel function mode, be sure you are in dMX mode. use the Menu button to select
"CH" followed by two digits. then use the ▲ and ▲ buttons to change the setting from 01, 02, or 04.
Your dimmer pack is initially set as a four channel dMX switcher.
05.
the dimmer pack is initially set to be activated by dMX address one. to change this setting be sure you
are in dMX mode. use the Menu button to select the address settings, this will be indicated by an "a"
in the first character of the lCd followed by three numbers. use the ▲ and ▲ buttons to select your desired
dMX address. Remember the dMX address tells your dMX controller what channel to activate the pack's
functions.
