User Manual; Product Overview Panorama Head - Rollei Easy Traveler Video Anleitung

Rollei Easy Traveler Video User Manual
14
Thank you for choosing our products! Read carefully before use .

Product Overview Panorama Head

1 1/4 inch screw
2 Quick release plate
3 1/4-inch thread
4 Tilt lock knob
5
Spirit level
6
Base plate
7
Hidden Allen key
1
2
3
4
5
6
12
13
ENGLISH
8 Platform locking knob
9 Handle lock and angle
adjustment knob
10 Handle length lock
11
Handle
12
Panorama locking knob
13
Ball joint
14 Ball-locking lever
7
8
9
10
11
14
