CPFE500F Handbook
Input Parameters
Parameter
Nominal input voltage
Input frequency range
Maximum input current
Output Parameters
Voltage Adjustment Range
designation
12 9.6 - 14.4V
24 22.4 - 33.6V
28 22.4 - 33.6V
48 38.4 - 57.6V
SELV Outputs
The CPFE500F-12 and CPFE500F-24 are classed as having SELV outputs. The CPFE500F-48 is classed as having
a Non-SELV output.
Input Connections:
Mains input connection by 3way AMP 'Mate-n-lock' connector
Mating 3-way housing: AMP 350766-1.
Mating crimp terminals: AMP 926893-1 (14~20AWG), 926895-1 (18~24AWG)
Pin 3 : Live, Pin 2 : Earth, Pin 1 : Neutral
Fusing: Internal fuse (F1): F15AH, 250V fuse 6.3x32 mm.
Output Connections:
DC output +ve & -ve connection by two M6x18 studs, max torque 4.4Nm.
Use appropriate ring terminals and wire for the load and short circuit current.
Output Signals
Signal connections available on two 10-way 2.5mm header connectors (ref J2,J3).
Mating 10-way housing: Molex 22-01-1102.
Mating crimp terminals: 08 70 0064
Pinout :-
Note: Two shorting links (supplied) may be fitted at J2 or J3 to permanently enable the
3&4 and one link between pins 5&6 to permanently enable.
Value
100 - 240 Vac
50-60Hz
8.2A rms
Output Current
(V) (A)
42
18
18
10.5
J2,J3 Pin
1
2
3
4
5
6
7
8
9
10
Maximum Power
(W)
504
504
504
504
Function
+ Sense
- Sense
COM
- remote on/off
+ remote on/off
Aux
Current share
Trim
ENA
IOG
