Mapping: Diagnosis Message
Parameter Inhalt
Diag Code Diagnostic code
Flags Event type
Text ID Text ID as reference to
Diagnosis text as defined in
ESI file
Time Stamp Time Stamp ( value in ns)
Flags Parameter 1 Data type Parameter 1
Parameter 1 IO-Link Port
Flags Parameter 2 Data type Parameter 2
Parameter 2 Event Code
Flags Parameter 3 Data type Parameter 3
Parameter 3 Event Qualifier
r ... nur lesen
rw ... lesen und schreiben
Mögliche Werte
Bit 0...15: 0x0000 - not used
0xDFFF
0xE000 - Bit 16...31: Manufacturer
0xE7FF specific
0xE800 Bit 16...31: Emergency Error
Code from DS301 or DS4xxx
0xE801 - reserved
0xEDFF
0xEE00 - Bit 16...31: Profile specific
0xEFFF
0xF000 - not used
0xFFFF
Bit 0...3: 0x00 Info message
0x01 Warning message
0x02 Error message
0x0000 no Text ID
else Text ID reference to ESI file
0x0005 UINT8
0x01 Port X01
0x02 Port X02
... ...
0x08 Port X08
0x0006 UINT16
geräteabhängig (→ IODD-Beschreibung des IO-Link
Devices)
0x0005 UINT8
Bit 0..2: 0x1 PHL
0x2 DL
0x3 AL
0x4 APPL
Bit 3: 0x0 Source: Device
0x1 Source: Master
Bit 4...5: 0x1 Event Type: Info Message
0x2 Event Type: Warning Message
0x3 Event Error Message
Bit 6...7: 0x1 Message Type: Single
0x2 Message Type: Going
0x3 Message TYpe: Coming
