DESCRIPTION OF SYMBOLS PRESENTED ON THE DISPLAY

SYMBOLS FOR HEATING CIRCUITS

Symbol

SYMBOLS FOR OPERATION MODE INDICATION

Symbol

SYMBOLS FOR USER FUNCTIONS

Symbol
* The number indicates the first or the second time program.
User manual
Description
The first (mixing) heating circuit.
The second (direct) heating circuit.
D. h. w. warming.
Description
Room heating.
Room cooling.
Operation according to program timer - day temperature. *
Operation according to program timer - night temperature. *
Requested day temperature operating mode.
Requested night temperature operating mode.
D. h. w. warming according to program timer - switch-on interval. *
D. h. w. warming according to program timer - switch-off interval. *
Switch off.
Permanent switch-on of d. h. w. warming.
Manual operation mode.
Emission measurement.
Description
PARTY operation mode.
ECO operation mode.
Holiday operation mode.
One-time d. h. w. warming.
