Multi-Contact PV-AZM-1.5/6 Bedienungsanleitung Seite 5

Abisolierzange pv-azm series für mc3 und mc4
Inhaltsverzeichnis

Werbung

Advanced Contact Technology
(ill. 7)
Legen Sie das Kabel in den entspre-
chenden Querschnittsbereich. Achten
Sie darauf, dass das Kabel am Längen-
anschlag ansteht.
7
(ill. 8)
Drücken Sie die Zangengriffe ganz
zusammen.
8
(ill. 9)
Führen Sie die Abisolierzange in die
Ausgangsposition zurück und und
entnehmen Sie das abisolierte Kabel.
9
www.multi-contact.com
(ill. 7)
Insert the cable in the appropriate
cross-section range. Make sure that
the cable rests against the length
gauge stop.
(ill. 8)
Press the handles of the pliers fully
together.
(ill. 9)
Return the stripping pliers to the start-
ing position and take out the stripped
cable.
