Operating instructions
CONTENTS
1. Introduction.
2. Technical information.
3. Safety precautions.
4. Operation.
5. Maintenance.
6. Guarantee.
7. Certifications.
1. Introduction.
Dear customer,
In order to make a reliable operating of the
elevator tower TE-076P possible, we have
created this operating instruction.
Before use, you are required to read the
operating instructions.
Please note the technical data.
Our products undergo very rigorous testing
under strict conditions and they are monitored
continuously during the manufacturing
process.
In order to guarantee the lift function and
safety, the original parts of the manufacturer's
design must be used. If any parts other than
those of the manufacturer are used, or the
product is modified in any way, the user
forfeits all warranty rights to claim.
We reserve the right to modify design and
performance without prior notice when
contacting us with queries or ordering
spare parts the model type, year of manu-
facture, and serial number are to be
quoted.
2. Technical information.
2.1 - Elevator tower TE-076PS / TE-076PB.
2.2 - Designed to lift loads vertically up to
different heights as support for sets of
illumination.
VMB ESPAÑOLA, S.A.
ENGLISH
2.3 - Maximum load : 200 Kg.
2.4 - Minimum load : 25 Kg.
2.5 - Maximum height : 6,50 m.
2.6 - Minimum height : 1,83 m.
2.7 - Area of base : 2,4 x 2,4 m.
2.8 - Transport weight : 95 Kg.
2.9 - Construction material : Steel profiles DIN
2394.
2.10 - 5 profiles telescopic system operated
by cable of steel and guided by channelled
steel pulleys with ball bearings.
2.11 - Winch : 650 Kg. of maximum load with
automatic brake to stop the load.
Certification CE and GS TÜV.
2.12 - Cable : Steel DIN 3060. Quality 180 Kg/
mm 2 . Twisting - resistant.
2.13 - Cable diameter : 6 mm.
2.14 - Exclusive ALS system ( Auto-Lock
Security )
2.15 - Adjustable stabilizing disc feet in the
legs with ruber non slip supports.
2.16 - Anchor of the legs by safety catches.
2.17 - Spirit level to adjust the verticallity of the
tower.
2.18 - Antirust protection and electrolitic
cadmiated (S) or black polyester (B).
2.19 - Swivel wheels for the vertical transport
of the tower to its working location when
folded.
