Connect The Hardware - TP-Link TD-W9960 Schnellinstallationsanleitung

Connect the Hardware

If you don't need the phone service, just directly connect the modem router to the phone jack with the provided
phone cable, then follow steps 3 and 4 to complete the hardware connection.
Phone Jack
1
PHONE MODEM
DSL Splitter
Phone Cable
Phone(Optional)
* Image may differ from actual product.
DSL WPS WiFi RESET LAN1
ON/OFF
2
Modem Router
LAN2 LAN3 LAN4/WAN POWER POWER
ON/OFF
3
Turn on the modem router.
4
Wait for 2 minutes. The Power and DSL LEDs
will be on and stable. If there is only one LED,
it will flash slowly instead.
Note: If the LED status is different, please refer to FAQ > Q2.
English
Power Jack
Power Adapter
5
