Truma-Multivent
Two-stage 12 V
universal fan
Operating
instructions

Short Description

The Truma fan Multivent TBM
is designed for the air distrib-
ution on the heater Trumatic
S 2200 (fig. A), as a vapour
escape or as a ventilator in
the kitchen or in the bath-
room (fig. B) or to increase
the air output in existing
warm air distribution systems
with extremly long ducting.
Multivent
b
a
c
a = off
b = position 1/2
c = position 1
Operation
Switch to the desired power
level (b or c) on the control
panel.

Switching off

Switch off at the control
panel (a).

Technical data

determined in accordance
with EN 624 or Truma test
conditions
Power supply:
12 V D.C.
Current consumption:
0.23 A in position 1/2
0.5 A in position 1
Air output:
29.000 l/h in position 1/2
60.000 l/h in position 1
EEC Type Approval:
e1 022603
5
