SETUP

Fix the control unit at a suitable place with two screws and connect it to a mains outlet with the included
power unit.
Model FIB-203
Switch on the control unit with the power switch. The LEDs light up (6 colors change). You can adjust the
color change speed with the rotary control SPEED.
Model FIB-206
Connect the infrared sensor to the control unit. Then switch on the control unit with the power switch. The
included remote control allows convenient control of the fiber light. When actuating a button, always hold the
remote control in the direction of the sensor. There must be visual connection between the remote control
and the sensor.
The remote control is supplied with a battery inserted. An insulating foil between the battery and the battery
contacts prevents the battery from being discharged during storage. Prior to the first operation remove the
foil from the battery support on the rear side of the remote control. Otherwise operation of the remote control
is not possible.
If the range of the remote control decreases (3 meters as a maximum), replace the
battery. For this purpose, on the rear side of the remote control press the small bar with
the groove to the right and at the same time remove the battery support. For operation,
one 3 V button cell type CR 2025 is required. When inserting, pay attention that the
positive pole of the button cell shows upwards in the support.
CAUTION!
Danger of explosion when battery is replaced improperly. Only replace by the same type. Please dispose of
old and used batteries properly. Batteries are hazardous waste and should not be disposed of with regular
domestic waste!
