Network Topology

For the EAP
■
A typical network topology for the EAP is shown below.
Internet
Router
A computer running the EAP Controller software, which can be in the same or
different subnet with the EAPs, is used to centrally manage the EAPs.
You can get the EAP Controller software from our website http://www.tp-link.com.
For the CAP (FIT Mode)
■
A typical network topology for the CAP is shown below.
Internet
Router
The wireless controller can be in the same or different subnet with the CAPs.
And the management host is used to log in to the wireless controller to centrally
manage the CAPs.
7
Switch
Controller Host
Switch
Wireless Controller
Management Host
EAP
EAP
EAP
EAP Controller
CAP
CAP
CAP
Clients
Clients
