(122IO) DELUXE WALL MOUNT SURFACE SKIMMER ENGLISH SIZE: 4.875" X 7.25" PANTONE 295U 04/15/2016
1
For pool size 16' (488 cm) and below:
Unscrew the strainer grid from the threaded strainer connector (lower)
from inside of the pool.
Lower Hose
Connection
Inside of the
Pool Wall
EASY-SET ® POOL
2
Depending on the size of pool purchased.
For 16' (488 cm) and below pools with Strainer
a
Screw the hose adaptor B (12) to the
threaded strainer connector, from
inside of the pool.
For 18' (549 cm) and above pools with Large Strainer
a
Screw the hose adaptor B (12) to the
threaded strainer connector, from
inside of the pool.
S AVE THESE INSTRUCTIONS

SETUP INSTRUCTIONS

Upper Hose
Threaded Strainer
Connection
Threaded
Strainer
Connector
12
Threaded
Strainer
Connector
12
Lower Hose
Connector
Connection
Strainer
Grid
METAL FRAME POOL
b
Connect the other end of the
skimmer hose (11) to the
hose adaptor B (12).
b
Connect the other end of the
skimmer hose (11) to the
hose adaptor B (12).
English
122A
Upper Hose
Connection
Inside of the
Pool Wall
12
11
12
11
