(122IO) DELUXE WALL MOUNT SURFACE SKIMMER ENGLISH SIZE: 4.875" X 7.25" PANTONE 295U 04/15/2016
HOOK ASSEMBLY FOR EASY SET
1
NOTE: If you are using a METAL FRAME POOL, go to page 6.
Connect the skimmer
hose (11) to the
skimmer (5)
bottom connector.
2
Assemble the hook as shown. Adjust the opening of the hook (8) by
pressing and sliding the arm (9) at the same time.
Press
3
Loosen the skimmer
screw (6), attach the
assembled hook and hand
tighten the screw.
NOTE: Do not over
tighten or use tools
such as pliers.
S AVE THESE INSTRUCTIONS
®
POOLS WITH INFLATABLE TOP RINGS
Insert
8
Press
Insert
7
4
EASY-SET
water outlet connector (lower hose
connection). Adjust the hook to be
snug around the
6
inflated ring
Slide
(see step #2).
Ensure
the hook is
securely
tightened
over the
pool.
Press
9
Slide
Place the whole assembled
hook unit over the top of an
®
Pool Top Ring near the
English
122A
5
11
9
8
7
Inflatable
Top Ring
Page 5
