HOMCOM 842-289V90 Montageanleitung Seite 6

3. Remove the fixture fastener (C) from the firepit. Attach the firepit by aligning the post
through the umbrella hole, then tighten the fixture fastener (C) clockwise (see Figure 2).
umbrella hole
4. Insert glass shield (A) onto the top of fire pit body (B) (see Figure 3).
WARNING
DO NOT touch the surface of glass shield when in use or just after use. Allow 30
minutes after use to cool down to prevent scalding.
5. Place the glass beads (D) into the fire pit body (B). Approx. 1 kg of glass beads required
(see Figure 4).
NOTE: leave the pilot box uncovered by glass beads.
WARNING
Keep children away during assembly, as this item contains glass beads, which
are small pieces and can be swallowed by children.
pilot box
post
5
Figure 2
Figure 3
Figure 4
