3) The electric power supply cables must not show any damages, material fatigue (e.g. porous cables) or
sediments. Further instructions depending on the installation spot and usage have to be adhered by a
skilled installer and any safety problems have to be removed.
We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
There are no serviceable parts inside the device except for the fuse. Maintenance and service operations are
only to be carried out by authorized dealers.
Replacing the fuse
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Open the fuseholder on the rear panel with a fitting screwdriver.
Step 2: Remove the old fuse from the fuseholder.
Step 3: Install the new fuse in the fuseholder.
Step 4: Replace the fuseholder in the housing.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by a special power supply
cable available at your dealer.
Should you have further questions, please contact your dealer.
TECHNICAL SPECIFICATIONS
Power supply:
Power consumption:
Sound-control:
Maximum ambient temperature T
Maximum housing temperature T
Min. distance from flammable surfaces:
Min. distance to lighted object:
Fuse:
LED type:
Number of LEDs:
LED beam angle:
Dimensions (LxWxH):
Weight:
Accessories:
EUROLITE TPC-10 Coupler, black
Saveking Safety bond 3x600 black
Please note: Every information is subject to change without prior notice. 21.05.2015 ©
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
:
a
(steady state):
C
230 V AC, 50 Hz ~
20 W
via built-in microphone
45° C
60° C
0.5 m
0.1 m
F 1 A, 250V
3 W
4: RGBA
75° - 100°
460 x 160 x 200 mm
1 kg
No.
59006858
58010252
15/15
00071582.DOC, Version 1.1
