Parts list

Ref.Number Part Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
TR01A x 3pcs
TR04 x 30pcs
TR07 x 1pcs
TR010 x 1pcs
Description
TR01 Trampoline frame
TR02 Trampoline legs
TR03 Jump mat
TR04 Elastic springs
TR05 Cover pad
TR06 Top handle bar
TR07 adjust bar (top)
TR08 Handle bar(bottom)
TR09 Handle bar( connector)
TR10 Tool 1
TR11 Tool 2
TR12 Frame screws M8 x 80mm
TR13 Adjust Screws M8x35mm
TR14 Top bar screws M8x30mm
TR15 bottom screws M8x15mm
TR16 Manual
TR02 x 6pcs
TR05 x 1 pcs
TR08 x 1pcs
TR011 x 1pcs
-3-
Unit
3
6
1
30
1
1
1
1
1
1
1
2
1
1
2
1
TR03 x 1pcs
TR06 x 1pcs
TR09 x 1pcs
TR12 x 2pcs
