Annual Servicing

Please note that all AIRPRO MAX respirators should be serviced annually.
For further details on your nearest AIRPRO MAX authorised servicing centre details,
visit our website http://www.trend-uk.com.
NOTE: Repair is only by replacement of defective parts in accordance with
manufacturer instruction.

Before disassembly

Before disassembly or filter replacement, always clean contamination from the
respirator in accordance with the cleaning instructions on page 22.

Replacing the face seal

Detach press fastener from face seal and remove elastic from around headband (left
and right). Detach press fasteners from face shield frame (left and right).
Remove an old face seal by pulling the rubber seal out of the face shield channel.
Figure 22
24
Fit the new face seal by attaching the
press fastener to the mating press
fastener on the face shield frame.
Ensure pull tab is on the outside of the
face seal
Starting at the very top of the face
shield frame channel, firmly press the
ribbed edge strip fully into the channel
in the face shield frame.
Continue pressing in the ribbed edge
strip until you reach the end of the
channel.
Finish by attaching the press fastener on
the other side of the face shield frame.
(Figure 22)
