Enclosure with UV and weather protection
After some time, outdoor mounted plastics can lose their color and quality. Therefore, all hinged cover enclosures
are made of special white polycarbonate (PC). The light-stable colorants and additives are used to achieve
optimum protection of the polymer while maintaining color stability. The titanium dioxide used is especially
developed for polycarbonate and offers excellent UV protection through the reflection of the entire light spectrum
including the UV component around 340 nm. This effectively counteracts the otherwise occurring photochemical
polymer degradation. The color intensity is preserved for a long time without fading. The material is also resistant
to cold and frost.
Technical Specifications
Model
Power supply
Power consumption
Measuring range CO2
Measuring range temp
Analogue output
Accuracy CO2
Accuracy temperature
Air speed
Calibration
Sensor
Enclosure
Protection
Cable entry
Connection electrical
Pipe
Ambient condition
Storage condition
EU conformity
Johnson Controls, Inc., declares that these products are in compliance with the essential
requirements and other relevant provisions of the EMC Directive and Rohs Directive.
SCD-P1000-00-00
SCD-P2016-00-00
SCD-P2010-00-00
SCD-P2017-00-00
SCD-P2xxx
SCD-P2xxx
PT1000
NTC10k
SCD-P1xxx
SCD-P2xxx
SCD-P1xxx | -P2xxx Differential Pressure Transmitter
active, 1x 0..10V, CO2
active, 2x 0..10V, CO2 + temperature + PT1000
active, 2x 0..10V, CO2 + temperature
active, 2x 0..10V, CO2 + temperature + NTC10k
15..35 V = or 19..29 V ~ SELV
max. 2,3 W (24 V =) | 4,3 VA (24 V ~)
0..2000 ppm
0..+50 °C
1x/2x 0..10 V, min. load 10 kΩ
±50 ppm +3% of measured value (typ. @ 21 °C, 50% rH)
±0,5 K (typ. at 21 °C)
±0,3 °C / 0 °C acc. IEC 751 | EN 60751 Class B
±0,22 °C / 25 °C
min. 0,3m/s, max. 12m/s
self-calibration, Dual Channel
NDIR (non-dispersive, infrared)
PC, pure white, UV resistant
IP65 according to EN 60529
M20 flexible, for wire Ø=4,5..9 mm, removable
Removable plug-in terminal, max. 2,5 mm²
length=150 mm
length=180 mm
0..+50 °C, max. 85% rH, short term condensation
-30..+70 °C, max. 85% rH, short term condensation
2
PA6, black, Ø=19,5 mm
