PARTS LIST
No.
Description
1
Computer
2
Handlebar sponge
3
Handlebar post
4
Curved washer Ф8*19*1.5t
5
Allen bolt M8*20
6
Front end cap
7
Front stabilizer
8
Upper computer cable
9
Lower computer cable
10
Front plastic cover
11
Bearing
12
Pedal (L+R)
13
Crank end cap
14
Bolt M8*25
15
End cap
16
Chain cover (L+R)
17
Screw M5*15
18
Motor
19
Sensor with cable
20
DC cable
21
Rear end cap
22
Carriage bolt M8*75
23
Rear stabilizer
24
Nylon nut M8
25
Idler rack
26
Spring
27
Washer Ф10*19*1.5t
28
Carriage bolt M8*20
29
Carriage bolt M10*38
30
Tube spacer
31
C shape clip
32
Nylon nut M10
33
End Cap
34
Nut
Attention
Some of the above mentioned parts have already been assembled to a main body. These are not delivered separately!
ASSEMBLY
In order to familiarise yourself with the parts of the device, we advise you to study the overview picture and the parts list carefully before
you start assembly. Place all the parts on the floor and remove all packaging materials.
Step 1: Assembling the front and rear stabilizer
7
STEP 1
Attach the front stabilizer (7) to the main frame (46) with two square neck carriage bolts (22), two curved washers (4), two spring washers
(36) and two cap nuts (37).
Attach the rear stabilizer (23) to the main frame (46) with two square neck carriage bolts (22), two curved washers (4), two spring washers
(36) and two cap nuts (37).
All manuals and user guides at all-guides.com
Qty
No.
1
35
2
36
1
37
8
38
4
39
2
40
1
41
1
42
1
43
1
44
4
45
1
46
2
47
2
48
2
49
1
50
4
51
1
52
1
53
1
54
2
55
4
56
1
57
1
58
1
59
1
60
1
61
1
62
1
63
1
64
2
65
1
66
2
67
2
37
36
4
23
22
Description
Flywheel
Spring washer Ф8
Cap nut
Self-tapping Screw M4.5*25
Crank (L+R)
Screw M5*20
Belt
Allen bolt
Axle
Belt wheel
Conducting wire
Main frame
Inner plastic cover
Quick pin
M10 Knob
Washer Ф10*25*3t
End cap
Carriage bolt M10*35
Seat gliding set
Seat
Tube spacer
Seat post
Screw
Knob M8
Screw
Plastic cover (L+R)
End cap
Hand pulse cable
Hand pulse pads
Handle Bar
Combination wrench
Allen key wrench
Adapter
Qty
1
8
4
5
1
2
1
3
1
1
1
1
1
1
1
1
2
1
1
1
1
1
4
1
4
1
1
1
2
1
1
1
1
27
