INSTALLATION - INDOOR UNIT
1.Select a suitable location for installation.
2. Drill holes in the wall, insert the wall plugs in the
holes. Place the bracket and tighten the screws.
3. Connect the wires. Please pay
attention to the color markings
4. Mount the indoor unit on the bracket.
Make sure it is properly secured.
5. Plug in the AC adapter after making sure all the
wires are properly connected.
