Remote Control - Sharp 32BI4EA Schnellstartanleitung

EN
What is included in the box
Supply of this TV includes following parts:
• 1x TV
• 1x Remote control
• 2x AAA batteries
Attaching the Stand
Please follow the instructions in Technical leafl et, located in the
accessories bag.
Wall mounting the TV
1. Remove the four screws that are supplied in the wall mounting holes.
2.
The wall mount can now be easily attached to the mounting holes on
the rear of the TV.
3.
Install the wall mounting bracket to the television as advised by the
bracket manufacturer.
Connections
Connecting external devices see last page in this IM.
Getting started - initial set up
1.
If rubber or foam parts are attached to the TV-frame, remove them.
2. Using the RF cable, connect the TV to the TV Aerial wall socket.
3. For connecting to the Internet with a wired connection connect a
Cat 5/Ethernet cable (not included) from the TV to your broadband
modem/router.
4. Insert the batteries supplied into the Remote control.
5. Connect the power cable to the Electrical outlet.
6.
Then press Standby button to power on TV.
7. After turning the TV on, you will be welcomed by the First Time
Installation menu.
8. Please select language for TV menu.
9. Please set desired settings in remaining screens of First installation
menu.
TV buttons*
Vol+ Volume up and menu right
Vol- Volume down and menu left
CH+ Programme/Channel up and menu up
CH- Programme/Channel down and menu down
MENU Displays Menu/OSD
SOURCE Displays the input source menu
STANDBY Standby Power On/Off
* - for TV with buttons
• 1x TV stand installation packet
• 1x Quick Start Guide
TV Control Stick*
TV control stick is located on the lower left corner of back side of the TV.
You can use it instead of remote control to control most of the functions
of your TV.
While TV is in standby mode:
• short press of control stick - Power On
While watching TV:
• RIGHT/LEFT – volume up/volume down
• UP/DOWN – changes channel up/down
• short press – Displays Menu
• long press – Standby Power Off
While in menu:
• RIGHT/LEFT/UP/DOWN – navigation of cursor in on-screen menus
• short press – OK/Confi rm selected item
• long press – Back to previous menu
* - for TV with control stick
Choosing Mode Input/Source
To switch between the diff erent input/connections.
a) Using the buttons on the remote control:
1. Press [SOURCE/ ] - The source menu will appear.
2. Press [▲] or [▼] to select the input you require.
3. Press [OK].
b1) Using the buttons* on the Television:
1. Press [SOURCE].
2. Scroll up/down using CH+ / CH- buttons to the input/source you
require.
3. Press [VOL+] to change input/source to the one selected.
b2) Using the TV control stick*:
1. Shortly press control stick to enter menu.
2. Press control stick down and navigate cursor to SOURCES menu.
3. Shortly press control stick to enter SOURCES menu.
4. With control stick choose the input/source you require.
5. By short press of control stick, you will change input/source to the
one selected.
* - optional
TV Menu navigation
Use the (▲/▼/◄/►) buttons to focus on the desired item.
Press the OK button to select the item currently in focus.
Press the BACK button to go back one step in the menu.
Press the EXIT button to leave menu.
Press the HOME button to enter TV Home menu.
To enter Live TV menu, press the TV button and then press the MENU
button.
Electronic instruction manual
Find more useful information directly from your TV.
To launch the online manual, press the HOME button, select Apps from
the Home menu, and select "E-instruction Manual" from the apps list.
NOTE: An Internet connection is required to use this electronic manual.

Remote control

See in On Screen Manual in TV
