All manuals and user guides at all-guides.com BATTERYLOADTESTER RBA10 Battery Load Tester Tester de carga de la batería Batteriprovare Zkoušečka baterií Testeur de charge de batterie Aparelho de teste de carga da bateria Akun latauksen testaus Tester pentru nivelul de încărcare al bateriei...
înainte de testare 1. SETUP 1. KLARGØRING 1. OPPSETT 1. BEÁLLÍTÁS 2.1 – Schließen Sie die Klemmen an der Batterie an 2.1 – Sæt klipsene på batteriet 2.1 – Koble klipp til batteri 2.1 –...
All manuals and user guides at all-guides.com 3. BATTERY TEST 3.1 Take note of cold cranking amps (CCA) rating from battery label 3.2 If CCA rating is unknown, use the following table If voltage < 12V then recharge before testing 500A EN 1000 –...
Seite 4
All manuals and user guides at all-guides.com 3.6 Battery condition results 1 Battery in 2 Battery charge is low 3 Battery good condition Recharge and test again condition Is poor Observed CCA > Replace battery battery CCA 3.6 – Les résultats d'état de la batterie 3.6 –...
Seite 5
All manuals and user guides at all-guides.com 4.3 Use table to check cranking voltage is healthy e.g. If ‘load’ voltage was 11.2V then ‘cranking’ voltage should be at least 10.2V LOAD V (Min) CRANK V (Min) 10.2 10.4 10.6 10.8 11.0 11.2 10.2...
Seite 6
All manuals and user guides at all-guides.com 5.3 Hold engine revs at 3000RPM and observe charging voltage 5.4 Check results 1 Charging Voltage 2 Charging Voltage too low 3 Charging voltage is Normal Check belt & alternator too high Check regulator 5.3 –...
Seite 7
All manuals and user guides at all-guides.com 5.5 Switch ‘ON’ main electrical loads in vehicle 5.6 Hold engine revs at 2000RPM and observe charging voltage 5.7 Check results 1 Charging Voltage 2 Charging Voltage too 3 Charging voltage is Normal too high Check belt &...
Seite 8
All manuals and user guides at all-guides.com Ring Automotive Limited, Gelderd Road, Leeds, England LS12 6NA +44 (0)113 213 2000 +44 (0)113 231 0266 autosales@ringautomotive.co.uk www.ringautomotive.co.uk L408 Ring is a Registered Trade Mark...
