FOUR LFO
Specifications
Inputs
CV in
Type 4 x 3.5 mm TS jacks, DC coupled
Impedance >1 MΩ, unbalanced
Max input level 10 V p-p
Reset/Sync In
Type 4 x 3.5 mm TS jack, DC coupled
Impedance >1 MΩ, unbalanced
Max input level 10 V p-p
Outputs
Sine Out
Type 4 x 3.5 mm TS jack, DC coupled
Impedance >1 MΩ, unbalanced
Max output level 10 V p-p
Assign Out
Type 4 x 3.5 mm TS jack, DC coupled
Impedance >1 MΩ, unbalanced
Max output level 10 V p-p
Square Out
Type 4 x 3.5 mm TS jack, DC coupled
Impedance >1 MΩ, unbalanced
Max output level 10 V p-p
Controls
Sliders 4 x function attenuator
Mode (Reset/Sync) / Assign
Switches
(ramp, saw, triangle, trapezoid)
Button Function (Free, Quad, Phase, Divide)
LED Function (Free, Quad, Phase, Divide)
Power
Power supply Eurorack
Current draw 95 mA (+12 V) and 69 mA (-12 V)
Physical
Standard operating
5° C to 40° C (41° F to 104° F)
temperature range
71.12 x 128.5 x 32.6 mm
Dimensions
(2.80 x 5.05 x 1.28")
Rack units 14 HP
Weight 0.14 kg (0.31 lbs)
