buttons on the Live View page or by an Action Rule. The output will show as active
(shown under System Options > Ports & Devices) if the alarm device is activated.
• Digital input – An alarm input for connecting devices that can toggle between an open
and closed circuit, for example: PIRs, door/window contacts, glass break detectors,
etc. When a signal is received the state changes and the input becomes active (shown
under System Options > Ports & Devices).
Audio Connector
The Axis product has the following audio connectors:
• Audio in (pink) – 3.5 mm input for a mono microphone, or a line-in mono signal.
• Audio out (green) – 3.5 mm output for audio (line level) that can be connected to
a public address (PA) system or an active speaker with a built-in amplifier. A stereo
connector must be used for audio out.
SD Card Slot
NO TICE TICE
NO NO TICE
• Risk of damage to SD card. Do not use sharp tools or excessive force when inserting
or removing the SD card.
• Risk of data loss. To prevent data corruption, the SD card should be unmounted before
removal. To unmount, go to Setup > System Options > Storage > SD Card and click
Unmount.
This product supports SD/SDHC/SDXC cards (not included).
For SD card recommendations, see www.axis.com
Control Button
For location of the control button, see Hardware Overview on page 10.
The control button is used for:
• Resetting the product to factory default settings. See page 25.
• Connecting to an AXIS Video Hosting System service or AXIS Internet Dynamic DNS
Service. For more information about these services, see the User Manual.
