HOW THE UNIT WORKS
Humid air is drawn into the device by a rotating fan.
After passing through the filter, which stops dust
particles, the air is cooled by a cooling coil.
The water vapour in the air condenses into water,
which is discharged via a discharge hose.
The drier air is then heated by a heat exchanger and
blown back into the room by the fan.
Description of parts
1 housing
2 rating plate
3 cable
4 wheels
5 control panel/display
4
6 dry air outlet
7 condensation drain
8 handle/lever
9 air inlet
10 filter
