Anhang B — RS-232-Protokoll (Fortsetzung)

2.6.3.5 Pressure Units Read Command

This command returns the units the dispenser is using to display pressure.
Client command and data: (STX) + 04 + E4-- + E3 + (ETX)
The above text packet in hexadecimal format:
STX 0 4
0x02 0x30 0x34 0x45
NOTE: "D0" is the letter "D" followed by the digit "0."
Return Format: D0PUuu
uu: The pressure units. 00 = PSI, 01 = BAR, 02 = KPA
EXAMPLE: If the dispenser is set to display units of pressure in KPA, the text packet received from the dispenser is:
(STX) + 06 + D0PU02 + 1F + (ETX)
The above text packet in hexadecimal format:
STX 0 6
0x02 0x30 0x36 0x44

2.6.3.6 Vacuum Units Read Command

This command returns the units the dispenser is using to display vacuum.
Client command and data: (STX) + 04 + E5-- + E2 + (ETX)
The above text packet in hexadecimal format:
STX 0 4
0x02 0x30 0x34 0x45
NOTE: "D0" is the letter "D" followed by the digit "0."
Return Format: D0VUuu
uu: The vacuum units. 00 = KPA, 01 = Inches H
EXAMPLE: If the dispenser is set to display units of vacuum in H
(STX) + 06 + D0VU01 + 1A + (ETX)
The above text packet in hexadecimal format:
STX 0 6
0x02 0x30 0x36 0x44
www.nordsonefd.com/de info.de@nordsonefd.com
E 4 space space
0x34 0x20 0x20
D 0 P U
0x30 0x50 0x55
E 5 space space
0x35 0x20 0x20
O, 02 = Inches Hg, 03 = mmHg, 04 = TORR.
2
D 0 V U
0x30 0x56 0x55
+49 89 2000 338 600 Nordson EFD Verkaufs- und Kundendienst für Dosiersysteme stehen Ihnen weltweit zur Verfügung.
E 3 ETX
0x45 0x33 0x03
0 2 1 F
0x30 0x32 0x31 0x46
E 2 ETX
0x45 0x32 0x03
O, the text packet received from the dispenser is:
2
0 1 1 A
0x30 0x31 0x31 0x41
Ultimus V Präzisionsdosiergerät
ETX
0x03
ETX
0x03
