USERS MANUAL
Thank you for purchasing this Fore-
head thermometer. This thermo-
meter is designed with advance
infrared and ambient temperature
compensation technology for accu-
rate and fast temperature measure-
ments. It also has a wide range
mode to scan temperature real time.
display
Provission
for a strap
BC-12
Power on:
Press the "ON/MEN" button.
Power off:
Device will automatically power off
if left idle for more than 1 minute to
FOREHEAD THERMOMETER
extend battery life. In next power on,
it will get back to the default setting
of "HEAD" temperature function
CLEANING AND STORAGE
3. Remember to keep the temple
area clean and away from sweat,
The Probe is the most delicate part
cosmetics and scar while taking
of the thermometer. Use with care
temperature.
when cleaning the probe to avoid
4. During the measurement, please
damage.
away from the direct sunshine and
a. Allow the lens to fully dry for at
wind.
least 30 minutes.
5. The BC-12 is NOT waterproof. Do
b. Keep the unit dry and away from
not plunge into any liquid.
any liquids and direct sunlight.
c. Please use the alcohol swab or
CHANGING THE BATTERY
the soft cotton moistened with the
95% alcohol to clean the probe
It is supplied with one lithium cell
lens.
(CR2032x1pcs).
d. Clean the probe and probe lens
1. Open the battery compartment
after each use to ensure an
by turning the cover 45° clockwise
accurate reading and avoid cross
2. Remove the battery safety strip
contamination.
with a sharp-pointed object.
3. Insert a new battery under the
IMPORTANT NOTES
metal hook and press down until
1. Make sure the Probe is clean and
you hear a click sound
avoid the smothered with Rubber
4. Close the battery cover.
boat (Protector).
2. Before the measurement, please
stay in a stable environment for
5 mins and avoid the exercise,
bath for 30mins.
INTRODUCTION
MODE SELECTION
FOREHEAD Mode:
BC-12 set to
forehead-mode
stops fl ashing and two beeps are
sounded.
press
to measure
SCAN Mode:
the
temperature
On/Off
button
BC-12 set to
scan-mode
ON / OFF
will replace the "HEAD" icon in the
LCD display.
ENVIRONMENT
Exhausted batteries may
never be disposed of in
household waste but must
be handed in at your local
depot for chemical waste.
At the end of the product
lifecycle, you should not
throw this product into the
normal household garbage
but bring the product to a
collection point for the recycling of
electrical and electronic equipments.
DISPLAY READOUT
Device can not be powered
on to the ready stage.
Change with a new battery.
Battery is low and no more
measurements are possible.
Replace the battery.
Device stabilization in
process. Wait until 'HEAD'
stops fl ashing.
HOW TO USE
Measuring the FOREHEAD tempe-
The preset mode
rature:
of the thermometer
Always make sure the probe lens is
is forehead. The
clean without any damage, and the
thermometer is
forehead is clean.
ready for use after
the "Head" icon
Pres the "SCAN" button
and gently scan around
the temple area, you can
select the left side of the
left temples or the right side of the
While the unit is
right temples.
ON, hold down the
Measurement has been completed
"ON/MEN" button,
after a long beep is heard. (The
and press the
time of measurement might be
"Meas." button,
between 5~8sec (up to 30sec). That
then the
icon
depend on when the thermometer
get the highest temperature of the
forehead.)
Note: Forehead temperature is
displayed in Oral Mode. This mode
converts the forehead temperature
to display its "Oral equivalent."
error-1: Measurement before
device stabilization. Wait until
'HEAD' stops fl ashing.
error-2: The device showing a
rapid ambient temperature
change.
error-3: The ambient
temperature is not within the
range between 10°C and
40°C (50°F~104°F).
error-4 ~ error-9:
The system is not
functioning
properly. Unload the battery, wait for 1
minute and repower it. If the message
reappears, contact the retailer for service.
Temperature
taken is higher
than 42.2°C
(108.0°F) for forehead mode or 80°C
(176°F) for scan mode.
Temperature
taken is lower
than 34°C
(93.2°F) for forehead mode or –20°C
(-4°F) for scan mode.
Fever Alarm:
Memory Function:
Press the "ON/MEN"
If the thermometer detects a tempe-
button to see the
rature >37.5°C (or 99.5°F) under
temperature stored.
forehead mode, a long beeping
This thermometer provides 25 sets
sound followed by three short beep-
memory for the last measurements.
ing sounds to warn the user for
potential fever.
** Please be noted that only the
"HEAD" function's reading will be
Measuring temperature under SCAN
recorded. (When the thermometer
mode:
is turned off, the last measurement
When you press the "Meas" button,
data is saved into memory.)
you will get the temperature
immediately about 0.6 sec. If you
hold down the scan button, the
reading of measurement will be
continuous updated.
To change the LCD from °C to °F:
(This mode shows the
When the unit is OFF, hold down the
actual, unadjusted
"Meas." button, then press and hold
temperatures, which is
the "ON/MEN" button until the LCD
different with the forehead mode.)
shows '°F', then release the "Meas."
button. Use the same process to
ATTENTION: the BC-12 is NOT
change the LCD display from °F to
waterproof. The measuring of, for
°C.
example, the bath-water must be
done by pointing the thermometer
to the surface of the bath-water and
press the MEAS button.
SPECIFICATIONS
enclose your purchase ticket with the BC-12.
HOW TO ACT: If you notice a defect, consult
the manual fi rst. If this manual gives you no
Range:
defi nite answer, consult the Alecto Helpline on
34°C ~ 42,2°C (forehead)
telephonenumber +31 (0)73 6411 355.
-20°C ~ 80°C (scan)
THE GUARANTEE EXPIRES: When used
inexpert, leaking and faulty placed batteries, use
of unoriginal parts or accessories, negligence
Accuracy:
and defects caused by fi re, fl ood, stroke of
0,3°C (forehead)
lightning and natural disasters. With unqualifi ed
modifi cations or repairs by third persons. With
4% (scan)
incorrect transport without a suitable packing. If
the device is not handed in with the correct fi lled in
Operating Range: 10~40°C
guarantee card and the purchase ticket.
Storage conditions: -20°C ~ 50°C
NOT UNDER THIS GUARANTEE:
Battery: CR2032, 3V, lithium
batteries.
Lifetime battery: measure 40 hours
All further responsibilities, in particular subsequent
continuously
damages, are excluded.
DECLARATION OF CONFORMITY
The declaration
Service
of conformity is
available on the website:
Help
GUARANTEE
You have a guarantee of 12 MONTHS after
the date of purchase of this Thermometer. We
guarantee during this period the free repair of
defects caused by material- and construction
faults. This at the importers discretion. It is only
possible to claim to the guarantee when you
ver 1.2
CHANGE °C / °F
+31 (0) 73 6411 355
