Battery Replacement - Techno Line WS 9180 Bedienungsanleitung

station itself. These values may be reset at any time.
Pressing "SELECT" 1x displays the stored max. temperature
-
Pressing "SELECT" 2x displays the stored min. temperature
-
Pressing "SELECT" 3x returns to normal time display
-
To delete a max. or min. temperature, press "SET/RESET" while viewing the temperature. The station will
-
return to normal time display mode.
Temperature trend indicator
The arrow in the display shows if the outdoor temperature has risen within the last hour by more than 1 degree
(arrow points upward), fallen (arrow points downward) or remained constant (arrow straight).

BATTERY REPLACEMENT

The battery low indicator will appear in the display when the batteries of the sensor need to be replaced. Remove
the back cover and insert 2 AA batteries in the correct polarity. And then replace the back cover.
To register the sensor please press "Zz/REGISTER' for 3 seconds until flashing dashes appear in place of the
outside temperature. The station will now attempt to register the sensor.
The battery symbol in row 2 displays the battery power of the station. To replace the batteries, open the battery
compartment and insert 2x 1.5V AA new batteries in the correct polarity.
SPECIFICATIONS
Indoor temperature measuring range:
Outdoor temperature measuring range:
Resolution:
Accuracy:
Dimensions (Main station):
Dimensions (Outdoor sensor):
Power requirements (Main station):
Power requirements (Outdoor sensor):
Environmental reception effects
The station obtains the accurate time with wireless technology. Same as all wireless devices, the reception is
maybe affected by the following circumstances:

long transmitting distance

nearby mountains and valleys

near freeway, railway, airports, high voltage cable etc.

near construction site

among tall buildings

inside concrete buildings
 near electrical appliances (computers, TV's, etc) and metallic structures

inside moving vehicles
Place the station at a location with optimal signal, i.e. close to a window and away from metal surfaces or electrical
appliances.
Precautions
0°C to +50°C (32°F to 122°F)
-30°C to +70°C (-22°F to 158°F)
0.1°C/ 0.1°F
± 1°C/ 1°F
73 x 26 x 164mm
50 x 28 x 96mm
2 x AA Mignon LR06, 1.5V
2 x AA Mignon LR06, 1.5V
