PROCESSOR

A/D D/A converter:
Limiter:

USER INTERFACE

Presets:
Controls:

INPUTS AND OUTPUTS

Audio inputs:
Audio outputs:
USB (control/firmware update):

POWER SUPPLY SPECIFICATIONS

Power consumption at 1/8 power in
medium use conditions (*):
Power consumption at 1/3 power in
medium use conditions (**):
Power consumption with speaker on
but no signal (idle):
Inrush current:
* NOTE FOR THE INSTALLER: Values refer to 1/8 power under normal operating conditions (music program with rare or no clipping). For any
configuration type, we recommend considering them to be the minimum values for dimensioning.
** NOTE FOR THE INSTALLER: Values refer to 1/3 power under heavy operating conditions (music program with frequent clipping and
limiting). We recommend dimensioning in accordance with these values for professional installations and tours.

DIMENSIONS AND WEIGHT

Width:
Height:
Depth:
Weight:
Product features, specifications and appearance are subject to change without prior notice. dBTechnologies reserves the
right to make changes or improvements in design or manufacturing without any obligation to change or improve previously
manufactured products.
IA540R
54
24 bit / 48 kHz
Dual Active Peak, RMS, Thermal
Flat, dB Technologies speaker, User preset
Reset button
4x Analogue (Euroblock)
4x Analogue (Euroblock)
Type B USB
0.36 A (220-240V~) - 0.66 A (100-120V~)
0.7 A (220-240V~) - 1.4 A (100-120V~)
0.16 A (220-240V~) - 0.25 A (100-120V~)
3.8 A
222 mm (8.7 inch.)
44 mm (1.7 inch.)
256 mm (10.1 inch.)
1.82 kg (4.01 lbs.)
